Description

Form factor: M.2 2280
NAND Flash: 3D NAND
Controller: RTS5766DL
Dimensions (L x W x H): 80 x 22 x 3.13mm / 3.15 x 0.87 x 0.13inch (with heat sink)
80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink)
Weight: 9g / 0.32oz (with heat sink)
6.2g / 0.22oz (without heat sink)
Interface: PCIe Gen3 x4
Sequential Read (Max): Up to 2,400MB/s
Sequential Write (Max): Up to 1,800MB/s
4KB Random Read IOPS (Max): Up to 200K
4KB Random Write IOPS (Max): Up to 150K
Operating temperature: 0°C – 70°C
Storage temperature: -40°C – 85°C
Shock resistance: 1500G/0.5ms
MTBF: 1,500,000 hours
Terabytes Written (TBW): 520TB
Warranty: 3-year limited warranty
