CP PLUS ANW-HPU8H2D-N12 8+2 OUTDOOR POE SWITCH 100MBPS (2YEAR)
₹2,184.00
- Networking standard: IEEE 802.3i 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3x Flow Control, IEEE 802.3af/at/bt Power over Ethernet
- Support 6KV lightning protection, 8KV surge protection
- PoE Power Budget : 120W
- Support bt 60W High Power (PoE Port 7~8)
- Water Resistant AI PoE Switch
- AI Watchdog Function
- Support IP65 Rating
In stock
Description
| Network Port | PoE (1~6): 10/100Mbps PoE ports (RJ45) PoE (7~8): 10/100Mbps PoE ports (RJ45),Support bt 60W High Power LAN: 10/100Mbps uplink ports (RJ45) |
| Network Standard | IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x Flow Control IEEE 802.3af/at/bt Power over Ethernet |
| Transmission Rate | 200Mbps Full Duplex; 10 or 100Mbps Half Duplex |
| Transmission Distance | 1~2 ports 250m 10Mbps / 3~8 ports 130m 100Mbps |
| MAC Address List | 2K |
| Bandwidth | 2.0 Gbps |
| Network Latency | (10 to 100Mbps): ≤16μs (use the 64byte package size) |
| Frame Filter & Transmission Rate | 14800pps the most for 10Mbps port, 148800pps the most for 100Mbps port |
| Power Budget | 120W |
| Power Input | AC 180~240V, Total≤120W |
| Power Output | PoE 1~6 Port: 1/2(+52V), 3/6 (GND)≤30W PoE 7~8 Port: 1245(+53V), 3678 (GND) compatible 1/2 (+52V), 3/6 (GND)≤60W |
| Watchdog | Port 1~8 |
| Lightning Protection | 6KV, Per: IEC61000-4-5 |
| ESD Protection | 8KV, Per: IEC61000-4-2 |
| Operating Temperature | -30°C ~60°C |
| Weatherproof Standard | IP65 |
| Operating Humidity | 10%~90% (Non-condensing) |
| Storage Temperature | -40°C ~70°C |
| Storage Humidity | 5%~90% (Non-condensing) |
| Dimension | 310mm(L) x 260mm(W) x 100mm(H) |
| Weight | 1.6Kg |
| Package Content | AC Power Cable, User Manual |
